Additive Manufacturing With Aluminum Alloys
Aluminum is an ideal material for many aluminum 3D printer industries, including aerospace and automotive.
Eplus3D's 3d printing aluminum powders include Alsi10Mg, AlSi7Mg and Aheadd® CP1. These 3d printing aluminum alloys have been tested for use on Eplus3D's metal 3D printers. Eplus3D also offers a wide range of validated processes for each of the above materials to ensure that the performance of the 3D printed parts is fully met.
Eplus3D Aluminum AlSi10Mg/3.2382
Parts printed using Eplus3D Aluminum AlSi10Mg offer good strength, hardness and dynamic properties as well as good thermal properties and low weight.
Aluminum Alloys Typical Part Properties:
Density: 2.7 g/cm³
Tensile Strength: XY: 440 ± 30 MPa; Z: 460 ± 30 MPa
Yield strength: XY: 260 ± 20 MPa; Z: 230 ± 20 MPa
Elongation @ Break XY: 7 ± 3 %; Z: 7 ± 3 %
Hardness: 70 ± 3 HRB
Aluminum Alloys Typical Application Areas:
Aerospace
Automotive
Engineering
Density: 2.7 g/cm³
Tensile Strength: XY: 440 ± 30 MPa; Z: 460 ± 30 MPa
Yield strength: XY: 260 ± 20 MPa; Z: 230 ± 20 MPa
Elongation @ Break XY: 7 ± 3 %; Z: 7 ± 3 %
Hardness: 70 ± 3 HRB
Aluminum Alloys Typical Application Areas:
Aerospace
Automotive
Engineering
Eplus3D Aluminum AlSi7Mg
Parts printed using Eplus3D Aluminum AlSi7Mg demonstrate outstanding performance in elevated temperatures up to 200 °C. The fast and simple heat treatment procedure enables an affordable part production.
Aluminum Alloys Typical Part Properties:
Density: 2.68 g/cm³
Tensile Strength: XY: 423 ± 5 MPa; Z: 499 MPa
Yield strength: XY: 270 ± 5 MPa; Z: 287 MPa
Elongation @ Break 12.5 ± 0.5 %
Thermal conductivity: 150 - 170 W/(mK)
Aluminum Alloys Typical Application Areas:
Aerospace
Automotive
Engineering
Density: 2.68 g/cm³
Tensile Strength: XY: 423 ± 5 MPa; Z: 499 MPa
Yield strength: XY: 270 ± 5 MPa; Z: 287 MPa
Elongation @ Break 12.5 ± 0.5 %
Thermal conductivity: 150 - 170 W/(mK)
Aluminum Alloys Typical Application Areas:
Aerospace
Automotive
Engineering
Eplus3D Aluminum Aheadd® CP1
Parts printed using Eplus3D Aluminum Aheadd® CP1 combine ultra‑low density with exceptional stiffness, enabling lightweight, high‑performance components for demanding aerospace and automotive applications.
Aluminum Alloys Typical Part Properties:
Density: 1.5 g/cm³
Tensile Strength: 203
Yield strength: 23
Elongation @ Break 137
Aluminum Alloys Typical Application Areas:
Aerospace
Automotive
Engineering
